SV08/22M • SOLENOID VALVE ON/OFF 2 WAYS 2 POSITIONS • SAE-08-2 • 350 BAR • 23.0 LPM • STEED
SV08/22M
Description
THIS ON/OFF 2 WAYS 2 POSITIONS SPOOL TYPE SOLENOID VALVE (MANUAL OVERRIDE) USES A SAE-08-2 CAVITY, WITH OPERATING PRESSURE UP TO 350 BAR AND A FLOW CAPACITY OF 23.0 LPM. WHEN SOLENOID COIL IS DE-ENERGIZED, THIS VALVE ALLOWS FLOW FROM PORT 1 TO 2 AND REVERSE FLOW FROM 2 TO 1 IS BLOCKED. WHEN SOLENOID COIL IS ENERGIZED, ALOWS FLOW BETWEEN PORTS 2 AND 1 AND REVERSE. BRAND: STEED.
Stock Level:
Contact us for stock availability
Price:
$207.00
