EMDV-08-N-3J-0-00 • SOLENOID VALVE 3-WAY 2-POSITION SPOOL TYPE • C-8-3 • 350 BAR • 19 LPM • BUCHER
EMDV-08-N-3J-0-00
Description
THIS THREE-WAY, TWO-POSITION SPOOL TYPE SOLENOID VALVE FEATURES A C-8-3 CAVITY, OPERATES AT 350 BAR, AND FLOWS 19 LPM. WHEN SOLENOID COIL IS DE-ENERGIZED, THIS VALVE ALLOWS FLOW BETWEEN PORTS 1 AND 2 AND PORT 3 IS BLOCKED. WHEN SOLENOID COIL IS ENERGIZED, THE SPOOL IN THIS VALVE IS SHIFTED AND ALLOWS FLOW BETWEEN PORTS 1 AND 3 AND PORT 2 IS BLOCKED. THIS VALVE SHIFTS IN A CLOSED POSITION. BRAND: BUCHER.
Stock Level:
Contact us for stock availability
Price:
$222.00
