EMDV-08-N-07-0-00 • SOLENOID VALVE 2-WAY 2-POSITION NORMALLY OPEN SPOOL TYPE • C-8-2 • 350 BAR • 19 LPM • BUCHER
EMDV-08-N-07-0-00
Description
THIS TWO-WAY, TWO-POSITION NORMALLY OPEN SPOOL TYPE SOLENOID VALVE FEATURES A C-8-2 CAVITY, OPERATES AT 350 BAR, AND FLOWS 19 LPM. WHEN SOLENOID COIL IS DE-ENERGIZED, THIS VALVE ALLOWS FLOW FROM PORTS 2 TO 1 AND RESTRICTS FLOW FROM PORTS 1 AND 2. WHEN SOLENOID COIL IS ENERGIZED, THE POPPET IN THIS VALVE IS SHIFTED TO BLOCK FLOW FROM PORTS 2 TO 1 AND ALLOW REVERSE FLOW BETWEEN PORTS 1 AND 2 AT A HIGH-PRESSURE DROP. BRAND: BUCHER.
Stock Level:
In Stock
Price:
$230.33
