EMBV-10-N-4M-0-00 • SOLENOID VALVE 4-WAY 3-POSITION SPOOL TYPE • C-10-4 • 350 BAR • 40 LPM • BUCHER
EMBV-10-N-4M-0-00
Description
THIS FOUR-WAY, THREE-POSITION MOTOR SPOOL TYPE SOLENOID VALVE FEATURES A C-10-4 CAVITY, OPERATES AT 350 BAR, AND FLOWS 40 LPM. AT THE INITIAL POSITION, THIS VALVE ALLOWS FLOW BETWEEN PORTS 4, 2 & 1. WHEN THE UPPER SOLENOID COIL IS ENERGIZED, THE SPOOL IN THIS VALVE IS SHIFTED AND ALLOWS FLOW BETWEEN PORTS 1 AND 2 AND PORTS 3 AND 4. WHEN THE LOWER SOLENOID COIL IS ENERGIZED, THE SPOOL IN THIS VALVE IS SHIFTED AND ALLOWS FLOW BETWEEN PORTS 1 AND 4 AND PORTS 2 AND 3. BRAND: BUCHER.
Stock Level:
In Stock
Price:
$518.34
