EMBV-10-N-4L-0-00 • SOLENOID VALVE 4-WAY 3-POSITION SPOOL TYPE • C-10-4 • 350 BAR • 40 LPM • BUCHER
EMBV-10-N-4L-0-00
Description
THIS FOUR-WAY, THREE-POSITION CLOSED CENTER SPOOL TYPE SOLENOID VALVE FEATURES A C-10-4 CAVITY, OPERATES AT 350 BAR, AND FLOWS 40 LPM. AT THE INITIAL POSITION, FLOW IS TOTALLY RESTRICTED IN ALL PORTS. WHEN THE UPPER SOLENOID COIL IS ENERGIZED, THE SPOOL IN THIS VALVE IS SHIFTED AND ALLOWS FLOW BETWEEN PORTS 2 AND 1 AND PORTS 3 AND 4. WHEN THE LOWER SOLENOID COIL IS ENERGIZED, THE SPOOL IN THIS VALVE IS SHIFTED AND ALLOWS FLOW BETWEEN PORTS 3 AND 2 AND PORTS 4 AND 1. BRAND: BUCHER.
Stock Level:
In Stock
Price:
$537.78
