EMBV-08-N-4J-0-00 • SOLENOID VALVE 4-WAY 3-POSITION SPOOL TYPE • C-8-4 • 350 BAR • 15 LPM • BUCHER
EMBV-08-N-4J-0-00
Description
THIS FOUR-WAY, THREE-POSITION TANDEM CENTER SPOOL TYPE SOLENOID VALVE FEATURES A C-8-4 CAVITY, OPERATES AT 350 BAR, AND FLOWS 15 LPM. AT THE INITIAL POSITION, THIS VALVE ALLOWS FLOW BETWEEN PORTS 3 & 1 AND BLOCKS PORTS 2 & 4. WHEN THE UPPER SOLENOID COIL IS ENERGIZED, THE SPOOL IN THIS VALVE IS SHIFTED AND ALLOWS FLOW BETWEEN PORTS 2 AND 3 AND PORTS 1 AND 4. WHEN THE LOWER SOLENOID COIL IS ENERGIZED, THE SPOOL IN THIS VALVE IS SHIFTED AND ALLOWS FLOW BETWEEN PORTS 3 AND 4 AND PORTS 2 AND 1. BRAND: BUCHER.
Stock Level:
In Stock
Price:
$417.72
